Direct-On-Line Starters (Classic)

Direct-On-Line Starters (Classic) from Apex are designed for dependable direct motor starting in pumps, machinery and electrical control panels. The starter is supplied in S.S. housing with push-button operation and model options based on motor output and overload relay range.

Brand: Apex Starter
HSN Code: 85369010
Type Reference: AE/P-116 series
Housing: Push button operated S.S. housing
Standard Reference: As per IS 13947 (Part 4/Sec.1):1993 / IEC 947-4-1 (1990)
Motor Output Range: 0.37 kW to 25 kW, up to 30-40 HP depending on selected model
Relay Range: Available from 0.5-1 A up to 30-40 A based on variation
Application: Suitable for motor control panels, pump sets and industrial machinery starting applications

Note: Select the required variation from the dropdown before ordering.

Type Variation	AE/P-116 I / 0.37 kW / 0.5 HP / Relay 0.5-1 A / Std Pkg 8 Nos., AE/P-116 I / 0.55 kW / 0.75 HP / Relay 1-2 A / Std Pkg 8 Nos., AE/P-116 I / 0.75 kW / 1 HP / Relay 1-2 A / Std Pkg 8 Nos., AE/P-116 I / 1.1 kW / 1.5 HP / Relay 1.5-3 A / Std Pkg 8 Nos., AE/P-116 I / 1.5 kW / 2 HP / Relay 2-4 A / Std Pkg 8 Nos., AE/P-116 I / 2.2 kW / 3 HP / Relay 3-6 A / Std Pkg 8 Nos., AE/P-116 I / 4 kW / 5 HP / Relay 4-10 A / Std Pkg 8 Nos., AE/P-116 I / 4 kW / 5 HP / Relay 6-12 A / Std Pkg 8 Nos., AE/P-116 I / 5.5 kW / 7.5 HP / Relay 10-16 A / Std Pkg 8 Nos., AE/P-116 I / 7.5 kW / 10 HP / Relay 11-20 A / Std Pkg 8 Nos., AE/P-116 2D II / 4 kW / 5 HP / Relay 6-12 A / Std Pkg 4 Nos., AE/P-116 2D II / 7.5 kW / 10 HP / Relay 8-16 A / Std Pkg 4 Nos., AE/P-116 2D II / 9.3 kW / 12.5 HP / Relay 16-24 A / Std Pkg 4 Nos., AE/P-116 2D II / 11 kW / 15 HP / Relay 16-24 A / Std Pkg 4 Nos., AE/P-116 2D II / 15 kW / 20 HP / Relay 24-32 A / Std Pkg 4 Nos., AE/P-116 3D III / 25 kW / 30-40 HP / Std Pkg 4 Nos.

Type Variation

AE/P-116 I / 0.37 kW / 0.5 HP / Relay 0.5-1 A / Std Pkg 8 Nos., AE/P-116 I / 0.55 kW / 0.75 HP / Relay 1-2 A / Std Pkg 8 Nos., AE/P-116 I / 0.75 kW / 1 HP / Relay 1-2 A / Std Pkg 8 Nos., AE/P-116 I / 1.1 kW / 1.5 HP / Relay 1.5-3 A / Std Pkg 8 Nos., AE/P-116 I / 1.5 kW / 2 HP / Relay 2-4 A / Std Pkg 8 Nos., AE/P-116 I / 2.2 kW / 3 HP / Relay 3-6 A / Std Pkg 8 Nos., AE/P-116 I / 4 kW / 5 HP / Relay 4-10 A / Std Pkg 8 Nos., AE/P-116 I / 4 kW / 5 HP / Relay 6-12 A / Std Pkg 8 Nos., AE/P-116 I / 5.5 kW / 7.5 HP / Relay 10-16 A / Std Pkg 8 Nos., AE/P-116 I / 7.5 kW / 10 HP / Relay 11-20 A / Std Pkg 8 Nos., AE/P-116 2D II / 4 kW / 5 HP / Relay 6-12 A / Std Pkg 4 Nos., AE/P-116 2D II / 7.5 kW / 10 HP / Relay 8-16 A / Std Pkg 4 Nos., AE/P-116 2D II / 9.3 kW / 12.5 HP / Relay 16-24 A / Std Pkg 4 Nos., AE/P-116 2D II / 11 kW / 15 HP / Relay 16-24 A / Std Pkg 4 Nos., AE/P-116 2D II / 15 kW / 20 HP / Relay 24-32 A / Std Pkg 4 Nos., AE/P-116 3D III / 25 kW / 30-40 HP / Std Pkg 4 Nos.
