Three Phase DOL Starters (Compact)

Three Phase DOL Starters (Compact) are Apex compact DOL starters for three-phase motor starting. They are built for electrical panels, pumps and small industrial machinery where direct-on-line starting is required.

Brand: Apex Starter
HSN Code: 85369010
Type Reference: AE/P-145 Compact T.P.
Housing: Push button operated S.S. housing
Standard Reference: As per IS 13947 (Part 4/Sec.1):1993 / IEC 947-4-1 (1990)
Motor Output Range: 0.37 kW to 5.5 kW / 0.5 HP to 7.5 HP
Relay Range: 0.5-1 A up to 8-14 A based on model selection
Application: Suitable for three-phase motors, pump sets, machine tools and control panels

Note: Select the required variation from the dropdown before ordering.

Type Variation	AE/P-145 Compact T.P. / 0.37 kW / 0.5 HP / Relay 0.5-1 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 0.75 kW / 1.0 HP / Relay 1-2.5 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 1.1 kW / 1.5 HP / Relay 2-4 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 1.5 kW / 2.0 HP / Relay 2-4 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 2.2 kW / 3.0 HP / Relay 4-7 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 4 kW / 5.0 HP / Relay 5-10 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 5.5 kW / 7.5 HP / Relay 8-14 A / Std Pkg 12 Nos.

Type Variation

AE/P-145 Compact T.P. / 0.37 kW / 0.5 HP / Relay 0.5-1 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 0.75 kW / 1.0 HP / Relay 1-2.5 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 1.1 kW / 1.5 HP / Relay 2-4 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 1.5 kW / 2.0 HP / Relay 2-4 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 2.2 kW / 3.0 HP / Relay 4-7 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 4 kW / 5.0 HP / Relay 5-10 A / Std Pkg 12 Nos., AE/P-145 Compact T.P. / 5.5 kW / 7.5 HP / Relay 8-14 A / Std Pkg 12 Nos.
